AC/DC> Kapalı – Kapalı Anahtarlama Güç Kaynağı

Wattage :

15W~150W

Features　:

Miniature size, non-PFC

5G vibration, 70℃ operation

300VAC input surge

Suitable for critical applications

2 outputs are isolated for RID series

Model

Single：

RS-15 / RS-25 / RS-35 / RS-50 / RS-75 / RS-100 / RS-150

Dual：

RD-35 / RD-50 / RD-65 / RD-85 / RD-125 / RID-50 / RID-65 / RID-85 / RID-125

Triple：

RT-50 / RT-65 / RT-85 / RT-125

Quad：

RQ-50 / RQ-65 / RQ-85 / RQ-125

Wattage :

35W~350W

Features　:

Non-PFC, most economical models

Ultra compact and 1U low profile

300VAC input surge

No load power consumption: 0.2W~0.75W

5G vibration, 70℃ operation

Operating altitude up to 5000 meters

Complete safety certificates: IEC/EN60335-1(PD3), IEC/EN61558-1, -2-16; IEC/EN/UL60950-1 and GB4943

Model

：

LRS-35 / LRS-50 / LRS-75 / LRS-100 / LRS-150 / LRS-150F / LRS-200 / LRS-350

Wattage :

100W~1500W

Features　:

Non-PFC

Economical medium to high power models

Model

：

SE-450 / SE-600 / SE-1000 / SE-1500

Wattage :

75W~750W

Features　:

• Built-in active PFC function
• Full range input, complete functions

Model

Single：

SP-75 / SP-100 / SP-150 / SP-200 / SP-240 / SP-320 / SP-480 / SP-750 / PSP-600 / PSPA-1000

Triple：

TP-100 / TP-150 / TP-7503

Quad：

QP-150 / QP-200 / QP-320

Wattage :

200W~1000W

Features　:

Slim and Low profile (26~41mm)

Fanless design,free air convection

Built-in active PFC function150%

peak load capability(100ms)

DC OK active signal and redundant function(option)

Operating altitude up to 5000 meter (Note.5)

LED indicator for power on

Model

：

UHP-200(R) / UHP-350(R) / UHP-500(R) / UHP-750 / UHP-1000

Wattage :

150W~500W

Features　:

1U low profile

Built-in active PFC function

Fanless design

Model

：

USP-150 / USP-225 / USP-350 / USP-500

Wattage :

75W~500W

Features　:

1U Low profile with active PFC function: 75W~320W: 30 mm, 500W: 40.5 mm

Built-in constant current limiting circuit (RSP-75/100/150)

Built-in remote ON/OFF control (RSP-75/100/150/500)

Built-in remote sense (RSP-500 only)

Model

：

RSP-75 / RSP-100 / RSP-150 / RSP-200 / RSP-320 / RSP-500

Wattage :

75W~1000W

Features　:

• Built-in active PFC function
• High efficiency, no load power consumption <0.5W~0.75W
• 5 years warranty

Model

：

HRP-75 / HRP-100 / HRP-150 / HRPG-150 / HRP-200 / HRPG-200 / HRP-300 / HRPG-300 / HRP-450 / HRPG-450 / HRP-600 / HRPG-600 / HRPG-1000

Wattage :

100W~1000W

Features　:

Medical level, built-in active PFC

Medical safety approved (MOOP level)

High efficiency, no load power consumption<0.5W~0.8W

5 years warranty

Model

：

MSP-100 / MSP-200 / MSP-300 / MSP-450 / MSP-600 / MSP-1000

Wattage :

100W~600W

Features　:

90~305VAC with PFC

Fanless design

High efficiency up to 96%

Wide working temperature range -55~+70℃(-40~+70℃ for HEP-600, -55~+65℃ for HEP-480)

Rugged metal case with IP65 design (IP68 option available), withstand 10G vibration

Operating altitude up to 5000 meters

Suitable for high/low temperature, high dust, high moisture, high vibration, high salt outdoor or harsh environment

6 years warranty

Model

Single：

HEP-100 / HEP-150 / HEP-185 / HEP-240 / HEP-320 / HEP-480 / HEP-600



DC output voltage adjustable

No load power consumption <0.3W

Assemble on industrial rail TS-35 / 7.5 or 15

Suitable for building automation and control of household appliance
